| S036-RS Series 3 – Scissor Lift | ||
| Features | ||
| Proportional Joystick Controls | ||
| Self-Locking Gates | ||
| One-Way Platform Extension Deck | ||
| Drivable At Full Height | ||
| Non-Marking Tyres | ||
| 4×2 Drive | ||
| Platform Load Sense System | ||
| Emergency Descent System | ||
| Tubing Explosion-Proof System | ||
| Onboard Fault Diagnostic System | ||
| Tilt Alarm | ||
| Motion Alarm | ||
| Horn | ||
| Hour Meter | ||
| Safety Arm For Troubleshooting | ||
| Standard Transport Forklift Holes | ||
| Charging Protection System | ||
| Flashing LED Beacon | ||
| Foldable Guard Rails | ||
| Automatic Pothole Protection | ||
| Drive Enable | ||
| One-Way Platform Extension Deck | ||
| Manual Brake Release | ||
| Lanyard Attachment Point | ||
| Tie-Down And Lifting Points | ||
| S036-RS Series 3 – Scissor Lift | ||
| Size | Metric | British |
| Max. Working Height | 5.6m | 18ft 5in |
| Max. Platform Height | 3.6m | 11ft 10in |
| Overall Length | 1.44m | 4ft 9in |
| Overall Width | 0.76m | 2ft 6in |
| Overall Height(Rails Up) | 1.99m | 6ft 6in |
| Overall Height(Rails Down) | 1.62m | 5ft 4in |
| Platform Size(Length×Width) | 1.29m x 0.70m | 4ft 3in x 2ft 4in |
| Platform Extension Size | 0.60m | 2ft |
| Ground Clearance | 0.06m/0.015m | 2in/1in |
| Wheelbase | 1.05m | 3ft 5in |
| Turning Radius | 0.40m/1.55m | 1ft 4in/5 |
| Tyres | φ230×80mm | φ230×80mm |
| S036-RS Series 3 – Scissor Lift | ||
| Performance | Metric | British |
| SWL | 240kg | 529lb |
| SWL On Extension | 100kg | 220lb |
| Max. Occupants | 2 | 2 |
| Gradeability | 25% | 25% |
| Travel Speed(Stowed) | 4.0km/h | 4.0km/h |
| Travel Speed(Raised) | 0.5km/h | 0.5km/h |
| Max. Working Slope | 1.5°/3° | 1.5°/3° |
| Up/Down Speed | 27/20sec | 27/20sec |
| S036-RS Series 3 – Scissor Lift | ||
| Weight & Power | Metric | British |
| Weight | 920kg | 2028lb |
| Hydraulic Tank | 3L | 3L |
| Battery | 2x12V/85Ah | 2x12V/85Ah |
| Charger | 24V/15A | 24V/15A |
| Driving Motor | 2x24VDC/0.4kW | 2x24VDC/0.4kW |
| Lifting Motor | 24VDC/1.2kW | 24VDC/1.2kW |
