S08-ACE – Scissor lift

Compact Scissor

  • World-First Compact Design – Same compact base size as a traditional 7.8m scissor lift, but delivers 9.6m working height for unprecedented access in tight spaces
  • Enhanced Maneuverability – Compact footprint allows access to confined areas previously impossible with traditional 9.6m scissor lifts
  • Maximum Versatility – Combines the working height of larger units with the agility of smaller models
  • Breakthrough Space Efficiency – Compact base dimensions provide superior access in space-constrained environments
  • Reduced Setup Requirements – Smaller footprint means less space needed for positioning and operation
ADD TO QUOTE
Categories: , Tag:

Description

S08-ACE Scissor Lift
Features – Standard Items
Proportional Joystick Controls
Self-Locking Gates
One-Way Platform Extension Deck
Drivable At Full Height
Non-Marking Tyres
Two-Wheel Drive
Two-Wheel Steering
Automatic Braking System
Emergency Descent System
Tubing Explosion-Proof System
Onboard Fault Diagnostic System
Tilt Alarm
Motion Alarm
Horn
Hour Meter
Safety Arm For Troubleshooting
Standard Transport Forklift Holes
Charging Protection System
Flashing LED Beacon
Foldable Guard Rails
Automatic Pothole Protection
Drive Enable
Charging Indicator
Manual Brake Release
Lanyard Attachment Point
Tie-Down And Lifting Points
Platform Load Sense System
Emergency Stop Button
S08-ACE Scissor Lift
Size Metric British
Max. Working Height 9.60m 31ft 6in
Max. Platform Height 7.60m 24ft 11in
Overall Length 1.88m 6ft 2in
Overall Width 0.81m 2ft 8in
Overall Height (Rails Up) 2.32m 7ft 7in
Overall Height (Rails Down) 1.99m 6ft 6in
Platform Size (Length ×Width） 1.73m×0.74m 5ft 8in×2ft 5in
Platform Extension Size 0.90m 2ft 11in
Ground Clearance (Stowed/Raised) 0.09m/0.016m 4in/1in
Wheelbase 1.40m 4ft 7in
Turning Radius (Inside/Outside) 0m/1.70m 0m/5ft 7in
Tyres φ323×125mm φ323×125mm
S08-ACE Scissor Lift
Performance Metric British
S.W.L 230kg 507lb
S.W.L On Extension 113kg 249lb
Max. Occupants (Indoor/Outdoor) 2/0 2/0
Gradeability 25% 25%
Travel Speed (Stowed) 4.5km/h 2.80mph
Travel Speed (Raised) 0.6km/h 0.37mph
Max. Working Slope X-1.5°/Y-3° X-1.5°/Y-3°
Up/Down Speed 35/45sec 35/45sec
S08-ACE Scissor Lift
Weight & Power Metric British
Overall Weight 2180kg 4806lb
Hydraulic Tank 11L 2.7gal
Lead-acid Battery 24V/185Ah 24V/185Ah
Lithium Battery 24V/180Ah 24V/180Ah
Charger 24V/30A 24V/30A
Driving Motor 2×24VAC/0.5kW 2×24VAC/0.5kW
Lifting Motor 24VAC/3.0kW 24VAC/3.0kW
S08-ACE Scissor Lift
