Available In:

Electric

S0812-ACE – Scissor Lift

Compact Scissor

  • Battery drive, equipped with fully sealed AC system (drive and lift), replacing traditional DC system (drive and lift)
  • Maintenance-free with improved efficiency, safety and more waterproof
  • Automatic pothole protection system – safe and reliable
  • Unidirectional extension platform – provides additional horizontal reach
  • Automatic display of fault codes for efficient troubleshooting and maintenance
ADD TO QUOTE
Categories: , Tag:

Description

S0812-ACE – Scissor Lift
Features
Proportional Joystick Controls
Self-Locking Gates
One-Way Platform Extension Deck
Drivable At Full Height
Non-Marking Tyres
Two-Wheel Drive
Two-Wheel Steering
Automatic Braking System
Emergency Descent System
Tubing Explosion-Proof System
Onboard Fault Diagnostic System
Tilt Alarm
Motion Alarm
Horn
Hour Meter
Safety Arm For Troubleshooting
Standard Transport Forklift Holes
Charging Protection System
Flashing LED Beacon
Foldable Guard Rails
Automatic Pothole Protection
Drive Enable
Charging Indicator
Manual Brake Release
Lanyard Attachment Point
Tie-Down And Lifting Points
Platform Load Sense System
Emergency Stop Button
S0812-ACE – Scissor Lift
Size Metric British
Max. Working Height 10.00m 32ft 10in
Max. Platform Height 8.00m 26ft 3in
Overall Length 2.48m 8ft 2in
Overall Width 1.15m 3ft 9in
Overall Height(Rails Up) 2.36m 7ft 9in
Overall Height(Rails Down) 1.83m 6ft
Platform Size(Length×Width) 2.27m×1.12m 7ft 5in×3ft 8in
Platform Extension Size 0.90m 2ft 11in
Ground Clearance(Stowed/Raised) 0.10m/0.019m 4in/1in
Wheelbase 1.87m 6ft 2in
TurningRadius(Inside/Outside) 0m/2.10m 0in/6ft 11in
Tyres φ381×127mm φ381×127mm
S0812-ACE – Scissor Lift
Performance Metric British
SWL 450kg 992lb
SWL On Extension 113kg 249lb
Max. Occupants 2 2
Gradeability 25% 25%
Travel Speed(Stowed) 5.0km/h 3.10mph
Travel Speed(Raised) 0.8km/h 0.50mph
Max. Working Slope X-1.5°/Y-3° X-1.5°/Y-3°
Up/Down Speed 34/30sec 34/30sec
S0812-ACE – Scissor Lift
Weight & Power Metric British
Weight(Lead-acid Battery) 2750kg 6063lb
Weight(Lithium Battery) 2750kg 6063lb
Hydraulic Tank 20L 5.3gal
Battery 24V/185Ah 24V/185Ah
Charger 24V/30A 24V/30A
Driving Motor 2×24VAC/0.87kW 2×24VAC/0.87kW
Lifting Motor 24VAC/3.50kW 24VAC/3.50kW
S0812-ACE – Scissor Lift
