Description
| S1008-ACE Scissor Lift |
| Features |
| Proportional Joystick Controls |
| Self-Locking Gates |
| One-Way Platform Extension Deck |
| Drivable At Full Height |
| Non-Marking Tyres |
| Two-Wheel Drive |
| Two-Wheel Steering |
| Automatic Braking System |
| Emergency Descent System |
| Tubing Explosion-Proof System |
| Onboard Fault Diagnostic System |
| Tilt Alarm |
| Motion Alarm |
| Horn |
| Hour Meter |
| Safety Arm For Troubleshooting |
| Standard Transport Forklift Holes |
| Charging Protection System |
| Flashing LED Beacon |
| Foldable Guard Rails |
| Automatic Pothole Protection |
| Drive Enable |
| Charging Indicator |
| Platform Load Sense System |
| Manual Brake Release |
| Lanyard Attachment Point |
| Tie-Down And Lifting Points |
| Emergency Stop Button |
| S1008-ACE Scissor Lift | ||
| Dimension | Metric | British |
| Max. Working Height | 12.00m | 39ft 4in |
| Max. Platform Height | 10.00m | 32ft 10in |
| Overall Length | 2.48m | 8ft 2in |
| Overall Width | 0.83m | 2ft 9in |
| Overall Height(Rails Up) | 2.51m | 8ft 3in |
| Overall Height(Rails Down) | 2.05m | 6ft 9in |
| Platform Size(Length×Width) | 2.27m×0.81m | 7ft 5in×2ft 8in |
| Platform Extension Size | 0.90m | 2ft 11in |
| Ground Clearance(Stowed/Raised) | 0.10m/0.019m | 4in/1in |
| Wheelbase | 1.87m | 6ft 2in |
| Turning Radius(Inside/Outside) | 0m/2.10m | 0in/6ft 11in |
| Tyres | φ381×127mm | φ381×127mm |
| S1008-ACE Scissor Lift | ||
| Performance | Metric | British |
| SWL | 250kg | 551lb |
| SWL On Extension | 113kg | 249lb |
| Max. Occupants (Indoor/Outdoor) | 2/1 | 2/1 |
| Gradeability | 25% | 25% |
| Travel Speed(Stowed) | 5.0km/h | 3.10mph |
| Travel Speed(Raised) | 0.8km/h | 0.50mph |
| Max. Working Slope | X-1.5°/Y-3° | X-1.5°/Y-3° |
| Up/Down Speed | 51/42sec | 51/42sec |
| S1008-ACE – Scissor Lift | ||
| Weight & Power | Metric | British |
| Overall Weight | 3150kg | 6944lb |
| Hydraulic Tank | 20L | 5.3gal |
| Battery | 24V/240Ah | 24V/240Ah |
| Charger | 24V/30A | 24V/30A |
| Driving Motor | 2×15VAC/0.87kW | 2×15VAC/0.87kW |
| Lifting Motor | 15VAC/3.5kW | 15VAC/3.5kW |
| S1008-ACE – Scissor Lift |
