Description
| S1412-ACE – Scissor Lift |
| Features |
| Proportional Joystick Controls |
| Self-Locking Gates |
| One-Way Platform Extension Deck |
| Drivable At Full Height |
| Non-Marking Tyres |
| 4×2 Drive |
| Platform Load Sense System |
| Emergency Descent System |
| Tubing Explosion-Proof System |
| Onboard Fault Diagnostic System |
| Tilt Alarm |
| Motion Alarm |
| Horn |
| Hour Meter |
| Safety Arm For Troubleshooting |
| Standard Transport Forklift Holes |
| Charging Protection System |
| Flashing LED Beacon |
| Foldable Guard Rails |
| Automatic Pothole Protection |
| Drive Enable |
| Tie-Down And Lifting Points |
| Manual Brake Release |
| Lanyard Attachment Point |
| S1412-ACE – Scissor Lift | ||
| Size | Metric | British |
| Max. Working Height | 15.70m | 51ft 6in |
| Max. Platform Height | 13.70m | 44ft 11in |
| Overall Length | 2.84m | 9ft 4in |
| Overall Width | 1.25m | 4ft 1in |
| Overall Height(Rails Up) | 2.62m | 8ft 7in |
| Overall Height(Rails Down) | 2.09m | 6ft 10in |
| Platform Size(Length×Width) | 2.64m×1.12m | 8ft 8in×3ft 8in |
| Platform Extension Size | 0.90m | 2ft 11in |
| Ground Clearance(Stowed/Raised) | 0.10m/0.019m | 4in/1in |
| Wheelbase | 2.22m | 7ft 3in |
| TurningRadius(Inside/Outside) | 0m/2.65m | 0in/8ft 8in |
| Tyres | φ381×127mm | φ381×127mm |
| S1412-ACE – Scissor Lift | ||
| Performance | Metric | British |
| SWL | 250kg | 551lb |
| SWL On Extension | 113kg | 249lb |
| Max. Occupants (Indoor/Outdoor) | 2/0 | 2/0 |
| Gradeability | 25% | 25% |
| Travel Speed(Stowed) | 5km/h | 5km/h |
| Travel Speed(Raised) | 0.8km/h | 0.8km/h |
| Max. Working Slope | 1.5°/3° | 1.5°/3° |
| Up/Down Speed | 70/67sec | 70/67sec |
| S1412-ACE – Scissor Lift | ||
| Weight & Power | Metric | British |
| Overall Weight(Lead-acid Battery) | 3360kg | 7407lb |
| Overall Weight(Lithium Battery) | 3270kg | 7209lb |
| Hydraulic Tank | 20L | 5.3gal |
| Battery | 4x12V/240Ah | 4x12V/240Ah |
| Charger | 24V/30A | 24V/30A |
| Driving Motor | 2×24VAC/0.87kW | 2×24VAC/0.87kW |
| Lifting Motor | 24VAC/3.5kW | 24VAC/3.5kW |
| S1412-ACE – Scissor Lift |
