Description
| SC1218-AWD – Scissor Lift |
| Features |
| Proportional Joystick Controls |
| Self-Locking Gates |
| One-Way Platform Extension Deck |
| Four-Wheel Drive |
| Two-Wheel Steering |
| Automatic Braking System |
| Self-Weight Lowering System |
| Tubing Explosion-Proof System |
| Onboard Fault Diagnostic System |
| Tilt Alarm |
| Motion Alarm |
| Horn |
| Hour Meter |
| Hydraulic Oil Cooling System |
| Flashing LED Beacon |
| Foldable Guard Rails |
| Drive Enable |
| Manual Brake Release |
| Lanyard Attachment Point |
| Standard Transport Forklift Pockets |
| Tie-Down And Lifting Points |
| Automatic Leveling Hydraulic Outriggers |
| Anti-Restart Engine Protection |
| Emergency Stop Button |
| Platform Load Sense System |
| Drivable At Full Height |
| Oscillating Axle Chassis |
| SC1218-AWD – Scissor Lift | ||
| Size | Metric | British |
| Max. Working Height | 14.30m | 46ft 11in |
| Max. Platform Height | 12.30m | 40ft 4in |
| Overall Length(Without Outriggers) | 3.19m | 10ft 6in |
| Overall Width(With Outriggers) | 3.84m | 12ft 7in |
| Overall Width | 1.76m | 5ft 9in |
| Overall Height(Rails Up) | 2.74m | 9ft |
| Overall Height(Rails Down) | 1.97m | 6ft 6in |
| Platform Size(Length×Width) | 2.88m×1.52m | 9ft 5in × 5ft |
| Platform Extension Size | 1.43m | 4ft 8in |
| Ground Clearance | 0.24m | 9in |
| Wheelbase | 2.29m | 7ft 6in |
| TurningRadius(Inside/Outside) | 2.15m/4.85m | 7ft 1in/15ft 11in |
| Tyres | 26×12-16.5 | 26×12-16.5 |
| SC1218-AWD – Scissor Lift | ||
| Performance | Metric | British |
| SWL | 363kg | 800lb |
| SWL On Extension | 136kg | 299lb |
| Max. Occupants | 3 | 3 |
| Gradeability | 40% | 40% |
| Travel Speed(Stowed) | 5.00km/h | 3.10mph |
| Travel Speed(Raised) | 0.45km/h | 0.28mph |
| Max. Working Slope | X-1.5°/Y-3° | X-1.5°/Y-3° |
| Up/Down Speed | 45/46sec | 45/46sec |
| SC1218-AWD – Scissor Lift | ||
| Overall Weight(With Outriggers) | 5050kg | 11133lb |
| Diesel Engine | 18.6kW/2400rpm | 18.6kW/2400rpm |
| Diesel Tank | 47L | 12.4gal |
| Hydraulic Engine | 71L | 18.7gal |
Note: Parameters with “★” are optional
