SL1323 – Rough Terrain Scissor Lift

Large All Terrain Scissor Series

  • Equipped with an integrated axle meeting varied requirements of 4WD&2WS, offering flexible operation and solid rough-terrain performance.
  • Diesel models are equipped with energy efficient yet powerful 18.2kW engines.
  • With maximum loads of 680kg and maximum working heights of 15m or 18m, the large platforms enable 4-7 people to work safely and comfortably.
  • All units feature a large 3.98m x 1.83m working platform with two-way extension decks measuring 1.43m x 1.16m respectively, which can be stopped at any point providing flexible operation.
  • With configuration of one key levelling function & automatic levelling, ensuring safe and stable operation.
ADD TO QUOTE
Categories: , Tag:

Description

Features

SL1323-AWD – Scissor Lift
Proportional Joystick Controls
Self-Locking Gates
Dual Slide-Out Platform Extension Deck
4×4 Drive
Drive axle
Wheel Braking
Self-Weight Lowering System
Tubing Explosion-Proof System
Onboard Fault Diagnostic System
Tilt Alarm
Motion Alarm
Horn
Hour Meter
Hydraulic Oil Cooling System
Flashing LED Beacon
Foldable Guard Rails
Drive Enable
Manual Brake Release
Lanyard Attachment Point
Tie-Down And Lifting Points
Automatic Leveling Hydraulic Outriggers
Anti-Restart Engine Protection
Emergency Pump
Emergency Stop Button
Platform Load Sense System
Oscillating Axle Chassis
SL1323-AWD – Scissor Lift
Size Metric British
Max. Working Height 15.00m 49ft 3in
Max. Platform Height 13.00m 42ft 8in
Overall Length(Without Outriggers) 3.98m 13ft 1in
Overall Width(With Outriggers) 4.88m 16ft
Overall Width 2.33m 7ft 8in
Overall Height(Rails Up) 3.02m 9ft 11in
Overall Height(Rails Down) 2.26m 7ft 5in
Platform Size(Length×Width) 3.98m/1.83m 13ft 1in ×6ft
Platform Extension Size 1.43m/1.16m 4ft 8in/3ft 10in
Ground Clearance 0.30m 1ft
Wheelbase 2.86m 9ft 5in
TurningRadius(Inside/Outside) 315/55/D20 7ft 9in/17ft 1in
Tyres 315/55/D20 315/55/D20
SL1323-AWD – Scissor Lift
Performance Metric British
SWL 680kg 680kg
SWL On Extension 227kg 500lb
Max. Occupants 7 7
Gradeability 40% 40%
Travel Speed(Stowed) 5km/h 3.1mph
Travel Speed(Raised) 1km/h 0.62mph
Max. Working Slope X-2°/Y-3° X-2°/Y-3°
Up/Down Speed 73/62sec 73/62sec
SL1323-AWD – Scissor Lift
Weight & Power Metric British
Overall Weight(Without Outriggers) 6970kg 15366lb
Overall Weight(With Outriggers) 7870kg 17350lb
Diesel Engine 18.2kW/3000rpm 18.2kW/3000rpm
Diesel Tank 100L 26gal
Hydraulic Engine 120L 26gal

Note: Parameters with “★” are optional
