Description
| SP030-E – Scissor Lift |
| Features |
| Self-Locking Gates |
| Emergency Descent System |
| Tubing Explosion-Proof System |
| Onboard Fault Diagnostic System |
| Tilt Alarm |
| Motion Alarm |
| Horn |
| Hour Meter |
| Safety Arm For Troubleshooting |
| Standard Transport Forklift Holes |
| Charging Protection System |
| Flashing LED Beacon |
| Charging Indicator |
| Lanyard Attachment Point |
| Tie-Down And Lifting Points |
| Platform Load Sense System |
| Emergency Stop Button |
| SP030-E – Scissor Lift | ||
| Size | Metric | British |
| Max. Working Height | 5.00m | 16ft 5in |
| Max. Platform Height | 3.00m | 9ft 10in |
| Overall Length | 1.31m | 4ft 3in |
| Overall Width | 0.75m | 2ft 5in |
| Overall Height | 1.80m | 5ft 11in |
| Platform Size(Length × Width) | 1.15m × 0.66m | 3ft 9in x 2ft 2in |
| Ground Clearance | 0.075m | 3in |
| Wheelbase | 1.14m | 3ft 3in |
| Tyres | φ200×50mm | φ200×50mm |
| SP030-E – Scissor Lift | ||
| Performance | Metric | British |
| SWL | 240kg | 529lb |
| Max. Occupants (Indoor/Outdoor) | 1/0 | 1/0 |
| Max. Working Slope | X-1°/Y-1° | X-1°/Y-1° |
| Up/Down Speed | 21/21sec | 21/21sec |
| SP030-E – Scissor Lift | ||
| Weight & Power | Metric | British |
| Weight | 398kg | 878lb |
| Hydraulic Tank | 3L | 0.8gal |
| Battery | 12V/85Ah | 12V/85Ah |
| Charger | 12V/15A | 12V/15A |
| Lifting Motor | 12VDC/0.8kW | 12VDC/0.8kW |
| SP030-E – Scissor Lift |
Note: Parameters with “★” are optional
